For high-volume stamped-part welding and riveting, the delivery bottleneck is rarely the speed of a single machine. It is the inter-process flow, the repeatability of fixturing and locating, and the pile-up at final inspection. Our approach: integrate welding and riveting into the stamping die (in-die joining) so the joining cycle matches the stamping cycle; replace manual sampling with full inspection machines to eliminate the final-inspection bottleneck; and ensure continuous production through equipment redundancy and die backup.

The conventional flow is: stamp, unload, stack, transfer to a separate welding/riveting station, then re-locate and re-clamp. Every load-unload and re-location adds cycle loss and cumulative positioning error.

In-die joining integrates the welding electrode or riveting mechanism directly into the stamping die. The part is formed, then joined without leaving its located state, and exits as a finished assembly in one stroke. The delivery benefits are direct: joining time is absorbed into the stamping cycle; secondary locating is eliminated; work-in-process and lead time drop.

The most common delivery risk in high-volume orders is a backlog at final inspection. Manual sampling is slow, and once a batch issue is found, a large quantity of parts faces rework or scrap.

We deploy full inspection machines that check every joined part inline. Checks can include: joint presence (missing weld/rivet), position deviation, visual defects, and where required, force or displacement monitoring for joint quality. The inspection cycle matches the line, creates no pile-up, and intercepts quality issues at the station rather than at final inspection.

If the volume is sufficiently large, we can dedicate specific machines to the order and stock up on raw materials in advance. Furthermore, our implementation of intelligent scheduling and production inspection systems helps shorten lead times and ensures timely delivery.

For a quote, please provide: part drawings and quantity. We will respond within 24 hours with a capacity assessment and delivery commitment. Info@shzhj.com
